Fontaine 40 Ton Mechanical Neck EXT (29'-50' or 34'-60')

Sold out
Contact for Price
Renegade LXT40 Air Tandem (Model: RENEGADELXT40)
Capacity: 40 tons in 16-foot length - GAWR and tire ratings determine legal loads
Load Base: 16-foot rigid 2-point load centered in deck
Compatibility: Designed to accept optional flip neck extension and third flip axle
Length / Width: 47 feet 11 inches ** unless 34 60 deck length selected then overall length is 53 - 102 inches wide
Gooseneck Design: Mechanical removable with removable fifth wheel guide rollers - Combination figure-8 plate which provides 50 inches and 52 inches loaded - Swing radius of 81 inches
Gooseneck Platform: Full width gooseneck platform with 1 1/8 inch wood floor
Deck Design: Flat level telescopic deck design
Deck Length: 29 feet 0 inches clear deck length (retracted) - 50 feet 0 inches (extended)
Loaded Deck Height: 20 inches with 6 inches ground clearance
Number of Axles: 2
Axle Capacity: 25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other components.
Tires: 255/70R 22.5 H ply OEM Standard
Wheels: 8.25 x 22.5 steel disc - hub-piloted
Width: 8 feet 6 inches
